Network Adapter Card Installation Guide

65

9. Select OK.

The AT-Setup utility copies the adapter driver from the Installation CD
to the system’s hard disk and integrates it with the system’s operating
system. The entire process can take up to 30 seconds to complete.

Note

If you see the error message “Failed to remove network adapter for
update. The data is invalid.”, click OK. The message can be ignored.

10. If the card is already installed in the system, the AT-Setup utility

displays the message in Figure 20 once the driver is installed. Click
OK. To complete the installation, connect the twisted pair cable or the
fiber optic cable to the port on the adapter.

Figure 20. AT-Setup Window - Completion

Note

To configure the adapter’s settings, refer to “Configuring the
Network Adapter Card Settings” on page 91.
