Network Adapter Card Installation Guide

23

Type of Cabling

50/125 or 62.5/125 micron (core/
cladding) multimode fiber optic
cable

Operating Specifications

Wavelength: 1310 nm

Output power - 50/125 micron
cabling:

Minimum: -22.5 dBm
Maximum: -14 dBm

Output power - 62.5/125 micron
cabling:

Minimum: -19.0 dBm
Maximum: -14 dBm

Input sensitivity:

Minimum: -31 dBm
Maximum: -14 dBm

Wake on LAN Feature

AT-2700FX Series

Supported

AT-2701FX Series

Supported

Default Setting

Disabled

BootPROM Chip and MBA Feature

AT-2700FX Series

Optional

AT-2701FX Series

Standard

Load Balancing and Fail-over Protection

AT-2700FX Series

Not supported

AT-2701FX Series

Supported

2

Default setting: Disabled

1. Numerous factors, such as too many splices or poorly implemented splices,

can significantly reduce the maximum distance of a fiber optic port. Fiber optic
cable should only be installed by a qualified fiber optic cable contractor.

2. Microsoft Windows 2000, 2003, and XP.

Table 4. AT-2700FX and AT-2701FX Series Network Adapter

Cards (Continued)
