Network Adapter Card Installation Guide

177

3. At the DOS prompt, do one of the following:

If you copied the program files onto diskette, type:

a:\diag

If you are using a driver installation diskette, type:

a:\diag\diag

If you are using the Installation CD, type:

x:\drivers\diag\diag

where x: is the drive letter for the CD drive.

If the system contains just one Allied Telesyn adapter card, the
AT-Diag main menu is displayed, as shown in Figure 108.

Figure 108. AT-Diag Main Menu

The card’s model number, MAC address, and speed and duplex mode
are displayed at the top of the window. Also included is the default port,
which applies only to dual port adapters and specifies the port where
the Managed Boot Agent (MBA) is active, and the status of the
BootPROM chip.

Diagnostic Tests
Communication Test
Hardware Information
Settings
Select Adapter
Technical Support

MAC Address Speed / Duplex Default Port DefaultROM

00:30:84 32:8A:50 100Mb / Full 100Mb Fiber Enabled

Esc - Exit

AT-2701FX Ethernet Adapter Diagnostics v3.0

Allied Telesyn, Inc.
