Chapter 1: Network Adapter Card Overview
34
LEDs
Table 9 describes the LEDs on the AT-2745FX and AT-2746FX Series
adapter cards. The 10Base-FL port uses the 10 LED and the 100Base-FX
port uses the 100 LED.
Table 9. AT-2745FX and AT-2746FX Series LEDs
LED
Status
Description
10
Green
The 10Base-FL port
is operating at 10
Mbps, full-duplex
mode.
Amber
The 10Base-FL port
is operating at 10
Mbps, half-duplex
mode.
Flashing
The 10Base-FL port
is receiving or
transmitting network
packets at 10 Mbps.
100
Green
The 100Base-FX port
is operating at 100
Mbps, full-duplex
mode.
Amber
The 100Base-FX port
is operating at 100
Mbps, half-duplex
mode.
Flashing
The 100Base-FX port
is receiving or
transmitting network
packets at 100 Mbps.
