Chapter 10: AT-Diag Utility

178

Systems containing more than one Allied Telesyn adapter card display
a prompt similar to the following prior to displaying the main menu. You
can use this prompt to select the adapter card to test or configure. You
can configure only one card at a time.

Figure 109. Select NIC Menu

4. To select a menu option, type the highlighted letter or use the up and

down arrow keys to highlight the desired option and press Return.

Note

The selections in the main menu are described in the following
sections.

5. If the system contains more that one network adapter card, use the

Select Adapter selection to change adapters to test or configure.

6. When you are finished running diagnostics, press Esc. The command

prompt is displayed again.

7. Remove the program diskette from the disk drive and reset the

computer to restart the system’s operating system.

0: AT-2701FX 00:30:84 33:33:8C

Select NIC

1: AT-2701FX 00:30:84 33:12:42
