Chapter 1: Network Adapter Card Overview

24

LED

The AT-2700FX and AT-2701FX Series have one LED, defined in Table 5.

Table 5. AT-2700FX and AT-2701FX Series LED

LED

Status

Description

100

Green

The port is operating
in full-duplex mode.

Amber

The port is operating
in half-duplex mode.

Blinking

The port is receiving
or transmitting
network traffic.
