Chapter 8: Operations, Administration, and Maintenance (OAM)
92
Figure 37. Module Configuration Menu (Line Card)
4. Select the port that you want to configure the OAM operations on.
5. Press .
The Port Management Menu, as shown in Figure 38, is displayed.
Figure 38. Port Management Menu
6. From the Port Management Menu, select OAM Configurations.
Module Configuration Menu
Converteon
Module 5
Module: AT-CM202
Port Link Speed Mode RX/ACT
A(100BaseFX) Offline 100M Full Off
B(100BaseTX) Offline 10M Half Off
Configure Operating Mode
Module name
Return to Module Status and Configuration Menu...
Port Management Menu
Module 5 - Port A
Port Configurations
OAM Configurations
Return to Module Configuration Menu...
