Chapter 7: Working with Line Cards and Other Modules
72
Displaying Basic Line Card Information
To display the status of the modules and line cards in the Converteon
chassis, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu, as shown in Figure 27, is
displayed.
Figure 27. Module Status and Configuration Menu
The fields are defined below:
Module
Displays the name of the module or line card and its slot number.
Status
Indicates the current status of the line card, whether there is no line
card inserted (--) or the correct line card is inserted in the slot and the
power is ON.
Module Status and Configuration
Converteon
Module Status Link(A) Link(B) OpMode
1: AT-CV5M01 On Offline
2: AT-CM202 On Offline Offline Link Test
3: AT-CM202 On Offline Offline Link Test
4:(Not Inserted) -- -- -- --
5: AT-CM202 On Offline Offline Link Test
6: AT-CM202 On Offline Offline Link Test
7: AT-CM202 On Offline Offline Link Test
8:(Not Inserted) -- -- -- --
9: AT-CM212A/1 On Offline Offline Link Test
10:AT-CM212A/1 On Offline Offline Link Test
11:AT-CM212A/1 On Offline Offline Link Test
12:(Not Inserted) -- -- -- --
13:AT-CM212B/1 On Offline Offline SML
14:AT-CM212B/1 On Offline Offline SML
15:AT-CM212B/1 On Offline Offline SML
16:(Not Inserted) -- -- -- --
More ...
Return to Main Menu ...
