AT-S70 Management Software User’s Guide
57
The Diagnostic Menu, as shown in Figure 20, is displayed.
Figure 20. Diagnostics Menu
4. From the Diagnostics Menu, select Chassis Diagnostics.
The AT-S70 management software runs the diagnostics on the chassis
and displays the Chassis Diagnostics menu, as shown in Figure 21.
Figure 21. Chassis Diagnostics Menu
Diagnostics Menu
Converteon
Chassis Diagnostics
Release Cycle Version
Line Card Image Version
Line Card Information
Return to Administration Menu...
Chassis Diagnostics Menu
Converteon
Serial Number:
MAC Address FF:FF:FF:FF:FF:FF
CONVERTEON Chassis: CV-5000 Chassis Revision V1.1.0
Running 0 days, 1 hours, 10 minutes, 9 seconds
Current Time: 00/00/00 01:10:47
Diagnostic Results:
Flash PROM Good
Serial Interface Good
RPSA Good Fan Status Failed Fan Temperature: 43 C
Fan 3.3V Power: 3.2 V Fan 5V Power: 4.9 V Fan 12V Power: 0.0 V
Fan1 Speed: Off Fan2 Speed: Off
RPSB Failed Fan Status Failed Fan Temperature: 35 C
Fan 3.3V Power: 3.2 V Fan 5V Power: 4.9 V Fan 12V Power: 11.7 V
Fan1 Speed: Off Fan2 Speed: Off
Hit any key to continue ...
