AT-S70 Management Software User’s Guide
123
The following screen is displayed, as shown in Figure 57.
Figure 57. TFTP - Enter Line Card Image File Name Window
6. Enter the IP address of the TFTP server.
7. Press .
The following screen is displayed, as shown in Figure 58.
Figure 58. TFTP - Enter Line Card Image File Name Window
8. Enter the filename of the line card image file that is to be stored as on
the TFTP server.
9. Press .
Once the filename has been specified, the following screen, as shown
in Figure 49, is displayed.
Figure 59. TFTP - Line Card Image Download Confirmation Window
10. Type Y for to start the download.
Converteon
TFTP Server IP Address->
Converteon
Image File Name->
Converteon
Ready to download application image through TFTP.
Warning: During Image Download Management activity is
disabled.
Do TFTP download now? (Yes or No):
