Chapter 9: File Downloads and Uploads
118
3. From the Administration Menu, select Image Download Through
TFTP.
The following screen is displayed, as shown in Figure 47.
Figure 47. TFTP - Software Image Downloading Window
4. Enter the IP address of the TFTP server.
5. Press .
The following screen is displayed, as shown in Figure 48.
Figure 48. TFTP - Enter Software Image File Name Window
6. Enter the filename of the image file that is to be stored as on the TFTP
server.
7. Press .
Once the filename has been specified, the following screen, as shown
in Figure 49, is displayed.
Figure 49. TFTP - Software Image Download Confirmation Window
Converteon
TFTP Server IP Address->_
Converteon
Image File Name-> _
Converteon
Ready to download application image through TFTP.
Warning: During Image Download Management activity is
disabled.
Do TFTP download now? (Yes or No):
