AT-S70 Management Software User’s Guide
121
Downloading Line Card Image Files
Downloading
Line Card Image
File Through
Xmodem
To download a new line card image file onto a chassis from a local
management session using Xmodem, perform the following procedure:
1. Start a local management session.
2. From the Main Menu, select Administration.
The Administration Menu, as shown in Figure 46 on page 117, is
displayed.
3. From the Administration Menu, select Linecard Image Download
Through XMODEM.
The following screen is displayed, as shown in Figure 53.
Figure 53. XModem - Line Card Image Download Window
4. Enter Y to start the download process or N to cancel.
5. If you enter Y, the following screen is displayed, as shown in Figure 52.
Figure 54. XModem - Line Card Image Slot Number Window
6. Enter the slot number that you wish to download the image file to.
7. Press .
Converteon
Ready to download application image via XModem.
Warning: During Image Download Management activity is
disabled.
Do XMODEM download now? (Yes or No):
Converteon
Ready to download application image via XModem.
Warning: During Image Download Management activity is
disabled.
Do XMODEM download now? (Yes or No):
Linecard Slot Number:
