AT-S70 Management Software User’s Guide
61
Displaying Line Card Information
To view la line card information, perform the following procedure:
1. From the Main Menu, select Administration.
The Administration Menu, as shown in Figure 18 on page 54, is
displayed.
2. From the Administration Menu, select Diagnostics.
The Diagnostic Menu, as shown in Figure 20 on page 57, is displayed.
3. From the Diagnostics Menu, select Line Card Information.
The Line Card Module Information window, as shown in Figure 23, is
displayed.
Figure 23. Line Card Module Information Window
Line Card Module Information
Converteon
Module MAC Address Serial Number
1: AT-CV5M01 000C469A214B 7
2: AT-CM202 323032055148 SN # 32
3: AT-CM202 323032055272 SN # 43
4:(Not Inserted) -- --
5: AT-CM202 323032055331 4#21
6: AT-CM202 323032055515 6#38
7: AT-CM202 323032055546 7#45
8:(Not Inserted) -- --
9: AT-CM212A/1 000C469A21E6 142
10: AT-CM212A/1 000C469A21E6 142
11: AT-CM212B/1 000C469A21DF 135
12:(Not Inserted) -- --
13: AT-CM212B/1 000C469A21DF 135
14: AT-CM212B/1 000C469A21DF 135
15: AT-CM212B/1 000C469A21DF 135
16:(Not Inserted) -- --
17: AT-CM202 323032055611 SN # 49
18: AT-CM202 323032055702 SN # 67
Hit any key to continue ...
