AT-S70 Management Software User’s Guide
119
8. Type Y for to start the download.
The following screen is displayed, as shown in Figure 50.
Figure 50. TFTP - Software Image Downloading Window
9. Begin the image file transfer.
After the system has downloaded the new image, it reboots the system
and begins to initialize the software. The system does not forward any
network traffic during the initialization process.
Note
Wait until the software is initialized before you attempt to reestablish
your management session.
Downloading
Software Image
File Through
Xmodem
To download a new AT-S70 software image onto a chassis from a local
management session using Xmodem, perform the following procedure:
1. Establish a local management session on the chassis where you
intend to download the new management software.
2. From the Main Menu, select Administration.
The Administration Menu, as shown in Figure 46 on page 117, is
displayed.
3. From the Administration Menu, select Image Download Through
XMODEM.
The following screen is displayed, as shown in Figure 51.
Figure 51. XModem - Software Image Download Window
Downloading Image through TFTP...........
Converteon
Ready to download application image through XModem.
Warning: During Image Download Management activity is
disabled.
Do XMODEM download now? (Yes or No):
