Chapter 9: File Downloads and Uploads
122
A message is displayed, as shown in Figure 55.
Figure 55. XModem - Line Card Image Downloading Window
8. Begin the image file transfer of the new management software image.
Note
The transfer protocol must be Xmodem or 1K Xmodem.
9. Proceed to the procedure in the “Downloading Files using Hilgraeve
HyperTerminal” section below.
Downloading
Line Card Image
File Through
TFTP
To download a new line card image file onto a chassis from a local
management session using Xmodem, perform the following procedure:
1. Start a local management session.
2. From the Main Menu, select Administration.
The Administration Menu, as shown in Figure 46 on page 117, is
displayed.
3. From the Administration Menu, select Linecard Image Download
Through TFTP.
The following screen is displayed, as shown in Figure 56.
Figure 56. TFTP - Line Card Image Download Window
4. Enter the slot number of the line card you wish to download the image
file to.
5. Press .
Ready to download linecard image.....
Converteon
Enter LineCard Slotnum: ->
