AT-S70 Management Software User’s Guide
51
Displaying System Status Information
The AT-S70 management software provides comprehensive status
information about the operation of the chassis and its components,
including detailed information about the line cards.
To view chassis status information, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu, as shown in Figure 16, is
displayed.
Figure 16. Module Status and Configuration Menu (1/2)
2. In the Module Status and Configuration Menu, click More ... to display
the remainder of the modules and line cards in the chassis, as shown
in Figure 17.
Figure 17. Module Status and Configuration Menu - 2/2
The Module Status and Configuration Menu displays basic information on
all the components currently installed in the chassis, including:
ˆ Line cards or CPM card (slots 1 through 18)
ˆ LED interface card (slot 19)
ˆ Rear expansion slot (slot 20)
ˆ Primary and redundant power supplies (slots 21 and 22)
The basic information displayed on the installed component is:
Module
Displays the name of the module or line card and its slot number.
Module Status and Configuration
Converteon
Module Status Link(A) Link(B) OpMode
17: AT-CM202 On Offline Offline Link Test
18: AT-CM202 On Offline Offline SML
19: LED On -- --
20:(Not Inserted) -- -- --
21: RPSA On
22: RPSB On
More ...
Return to Main Menu ...
