Broadcom Advanced Control Suite 3 User’s Guide
75
Note
You can specify up to four probe targets.
Note
The IP address assigned to either a probe target or team member
cannot have a zero as the first or last octet.
To configure LiveLink, do the following:
1. Click the Team Management button at the bottom of the BACS 3
window, or from the View menu, select Navigate, then Team
Management.
2. Select the Smart Load Balance and Failover or SLB (Auto-Fallback
Disable) team.
3. From the Teams menu, select Edit Team.
4. Click Expert Mode.
To configure LiveLink using the Teaming Wizard, see “Using the
Broadcom Teaming Wizard” on page 47.
5. In the Manage Teams window, click the Edit Team tab.
The Manage Teams Page: Edit Teams Tab is displayed. See Figure
37 on page 76.
6. Select Enable LiveLink. The LiveLink Configuration options appear in
Allied Telesis recommends accepting the default values for Probe
interval (the number of seconds between each retransmission of a link
packet to the probe target) and Probe maximum retries (the number
of consecutively missed responses from a probe target before a
failover is triggered).
