Chapter 1: Starting and Using BACS 3
30
Status
The result of the analysis for the indicated pair can be one of the following:
 Good. Good cable/PCB signal paths, but no gigabit link.
 Crossed. Pin short or crosstalk along two or more cable/PCB signal
paths.
 Open. One or both pins are open for a twisted pair.
 Short. Two pins from the same twisted pair are shorted together.
 Noise. Persistent noise present (most likely caused by Forced 10/
100).
 GB Link. Gigabit link is up and running.
 N/A. Algorithm failed to reach a conclusion.
Link
Indicates the link connection speed and mode.
Status
The status after the test is run, either completed or failed. There are
several factors that could affect the test results:
 Link partner. Various switch and hub manufacturers implement
different PHYs. Some PHYs are not IEEE compliant.
 Cable quality. Category 3, 4, 5, and 6 may affect the test results.
 Electrical interference. The testing environment may affect the test
results.
Setting Adapter
Properties
Selecting Options on the Configurations tab allows you to view and
change the values of the available properties of the selected adapter. The
potentially available properties and their respective settings are described
in this section.
Note
You must have administrator privileges to change the values for a
property.
Note
The list of available properties for your particular adapter may be
different. In addition, some properties may not be available for all
Allied Telesis or Broadcom-based network adapters.
