Broadcom Advanced Control Suite 3 User’s Guide
51
Figure 17. Creating/Modifying a Team: Team Type Page
9. From the Available Adapters list, click the adapter you want to add to
the team and then click Add. Remove team members from the Team
Members list by clicking the adapter and then clicking Remove. Click
Next.
The Creating/Modifying a Team: Assigning Team Members Page is
displayed. See Figure 18 on page 52.
Note
There must be at least one Broadcom network adapter assigned to
the team.
The TCP Offload Engine (TOE), Large Send Offload (LSO) and
Checksum Offload (CO) columns indicate if the TOE, LSO, and/or the
CO properties are supported for the adapter. The TOE, LSO, and CO
properties are enabled for a team only when all of the members
