Chapter 1: Starting and Using BACS 3
26
3. From the Select a test to run list, select Diagnostic Tests. If the
Diagnostic Tests option is not available, then from the Context View
tab on the right side of the window, select Diagnostics and then select
Diagnostic Tests.
The Diagnostics Test Page is displayed. See Figure 9 on page 26.
4. Select the diagnostic tests you want to run. Click Select All to select
all tests or Clear All to clear all test selections.
5. Click Run.
6. In the error message window that warns of the network connection
being temporarily interrupted, click Yes. The results are displayed in
the Status field for each test.
To run the diagnostic tests continuously, do the following:
1. Click the name of the adapter to test in the Device Management pane.
2. Click the Diagnostics tab. If the Diagnostics tab is not visible, then from
the View menu, select Navigate, then Device Management, and then
Diagnostics.
3. From the Select a test to run list, select Diagnostic Tests. If the
Diagnostic Tests option is not available, then from the Context View
tab on the right side of the window, select Diagnostics and then select
Diagnostic Tests.
The Diagnostics Test Page is displayed. See Figure 9.
Figure 9. Diagnostic Tests Page
4. Select the diagnostic tests you want to run. Click Select All to select
all tests or Clear All to clear all test selections.
5. Select Run Continuously.
6. Click Run.
