Broadcom Advanced Control Suite 3 User’s Guide
73
Figure 36. Manage VLAN(s) Page
9. Click Yes when the message is displayed indicating that the network
connection will be temporarily interrupted.
Note
To maintain optimum adapter performance, your system should
have 64 MB of system memory for each of the eight VLANs created
per adapter.
Displaying
VLANs and
Running VLAN
Tests
This section discusses how to display VLAN Properties and statistics as
well as how to delete VLANs.
To display VLAN properties and statistics and to run VLAN tests, do the
following:
1. Click the Team Management button at the bottom of the BACS 3
window, or from the View menu, select Navigate, and then Team
Management.
2. Select one of the listed VLANs.
3. Click the Information tab to view the properties of the VLAN adapter.
4. Click the Statistics tab to view the statistics for the VLAN adapter.
5. Click the Diagnostics tab to run a network test on the VLAN adapter.
