Broadcom Advanced Control Suite 3 User’s Guide
25
5. Click Run.
The results of the network test are displayed in the Result field of
Figure 8.
Figure 8. Network Test Page
Running
Diagnostic Tests
The Diagnostic Tests option on the Diagnostics tab lets you check the
state of the physical components on a Allied Telesis or Broadcom-based
network adapter. You can trigger the tests manually, or choose to have
BACS 3 continuously perform them. If the test are performed continuously,
then the number of passes and fails in the Status field for each test
increments every time the tests are performed. For example, if a test is
performed four times and there are no fails, the value in the Status field for
that test is 4/0. However, if there were 3 passes and 1 fail, the value in the
Status field is 3/1.
Note
You must have administrator privileges to run diagnostic tests.
Note
The network connection is temporarily lost while these tests are
running.
To run the diagnostic tests, do the following:
1. Click the name of the adapter that you want to test in the Device
Management pane.
2. Click the Diagnostics tab.
If the Diagnostics tab is not visible, then from the View menu, select
Navigate, then Device Management, and Diagnostics.
