Configuring Device Security
Defining Access Control
Page 77
Defining Access Control
Access Control Lists (ACL) allow network managers to define classification actions and rules for specific ingress
ports. Your switch supports up to 256 ACLs. Packets entering an ingress port, with an active ACL, are either
admitted or denied entry. If they are denied entry, the user can disable the port. ACLs are composed of access
control entries (ACEs) that are made of the filters that determine traffic classifications. The total number of ACEs
that can be defined in all ACLs together is 256.
This section contains the following topics:
• Defining MAC Based ACL
• Defining IPv4 Based ACL
• Defining IPv6 Based ACL
• Defining ACL Binding
Defining MAC Based ACL
The MAC Based ACL Page allows a MAC-based Access Control List (ACL) to be defined. The table lists Access
Control Elements (ACE) rules, which can be added only if the ACL is not bound to an interface.
To define a MAC Based ACL:
1. Click Network Security > MAC Based ACL. The MAC Based ACL Page opens:
Figure 43: MAC Based ACL Page
