Allied Telesis
AT-S94 Management Software Web Browser Interface User’s Guide
–
VLAN — Specifies the VLAN on which the access profile is defined.
•
Supported IP Format — Indicates the supported Internet Protocol on the device. Only IPv6 Global is
supported
•
IPv6 Address Type — Defines the type of configurable static IPv6 IP address for an interface. The possible
field values are:
–
Link Local — Specifies that link local addressing is supported by the interface.
–
Global — Specifies that global Unicast addressing is supported by the interface.
•
Link Local Interface — Specifies the interface on which IPv6 processing is enabled. The possible field
values are:
–
VLAN 1 — Specifies that VLAN 1 is supported.
–
None — Disables IPv6 support on the interface. This option is only available the first time you configure
the access profile.
–
Tunnel 1 — Specifies that ISATAP tunneling (Tunnel 1) mechanism is supported.
Note
You must initially select the VLAN 1 option to enable IPv6 support on the interface. After doing so, the
VLAN 1 and Tunnel 1 options are available, but the None option is not.
•
Source IP Address — Defines the interface source IP address to which the access profile applies.
The Source IP Address field is valid for a subnetwork.
–
Network Mask — Defines the network mask of the source IP address.
–
Prefix Length — Defines the number of bits that comprise the source IP address prefix, or the network
mask of the source IP address.
•
Action — Defines the action attached to the access rule. The possible field values are:
–
Permit — Permits access to the device.
–
Deny — Denies access to the device. This is the default.
3.
Define the fields.
4.
Click Apply. The access profile is saved and the device is updated.
5.
Click Save Config on the menu to save the changes permanently.
