Allied Telesis AT-TQ3600 User Manual
Page 43
AT-TQ3600 Wireless Access Point Installation Guide
43
Figure 19. Installing the Access Point on the Bottom Panel
2. If the LAN cable is external to the wall or ceiling, route it through the
notch in the cover and connect it to the LAN port. Refer to Figure 20 on
page 44.
Pin Hinges
Holes
