AT-TQ3600 Wireless Access Point Installation Guide
23
LEDs
The LEDs on the AT-TQ3600 Access Point are described in Table 3.
Note
You may turn off the LEDs with the management software.
Table 3. LEDs on the AT-TQ3600 Access Point
LED State Description
PWR Solid Green The unit is receiving DC power that is
within the normal operating range.
Off The power supply is not receiving power
from either the AC/DC power adapter or a
PoE Ethernet switch.
SYS Amber The access point is loading its firmware.
Off The unit is operating normally.
10M and
100M 10M: On
100M: Off The Ethernet port is operating at 10 Mbps.
10M: Off
100M: On The Ethernet port is operating at 100
Mbps.
10M: On
100M: On The Ethernet port is operating at 1000
Mbps.
2.4GHz Green The 2.4GHz radio is sending and receiving
radio waves.
5GHz Green The 5GHz radio is sending and receiving
radio waves.
