Installing the bottom panel on a wall or ceiling – Allied Telesis AT-TQ3600 User Manual
Page 40

Chapter 2: Installing the Access Point
40
Figure 16. Removing the Bottom Panel from the Wireless Access Point
You may now perform “Installing the Bottom Panel on a Wall or Ceiling” on
page 40.
Installing the
Bottom Panel on
a Wall or Ceiling
To install the bottom panel on a wall or ceiling, perform the following
procedure:
Note
If you are using wall anchors, start with step 1. If you are not using
wall anchors, start with step 4.
1. To install wall anchors, hold the bottom panel at the selected wall or
ceiling location and with a pencil or pen mark the locations of the four
screw holes that are to be used to secure the panel. Refer to Figure 17
on page 41.
Pin Hinges
