Allied Telesis AT-TQ3600 User Manual
Page 36
Chapter 2: Installing the Access Point
36
Figure 11. Screw Holes on the Bottom Panel of the AT-TQ3600 Bracket
The holes have a diameter of 4.5 mm (0.2 in.). Refer to Figure 12.
Figure 12. Hole Dimensions
Screw Holes
Screw Holes
4.5 mm
4.5 mm
