Media and tray_ 47
4. Squeeze the multi-purpose tray paper width guides and adjust them
to the width of the paper. Do not force them too much, or the paper
will bent resulting in a paper jam or skew.
5. When you print a document, set the paper type and size for the
multi-purpose tray. For information about setting the paper type and
size on the control panel (see "Setting the default tray and paper" on
page 49).
PRINTING ON SPECIAL MEDIA
The table below shows the available special media for each tray.
The paper setting in the machine and driver should match to print without a
paper mismatch error.
To change the paper setting set in the machine, from the Samsung Easy
Printer Manager select (Switch to advanced mode) > Device Set-
tings.
Or if your machine supports a display screen, you can set it using the
(Menu) button on the control panel.
Then, set the paper type from the Printing preferences window > Paper
tab > Paper Type (see "Opening printing preferences" on page 52).
When using special media, we recommend you feed one paper at a
time. Check the maximum input number of media for each tray (See
"Print media specifications" on page 110).
Types Tray 1 Optional tray
Multi-purpose
tray
Plain ● ● ●
Thick ● ● ●
Thicker ●
Thin ● ● ●
Bond ● ● ●
Color ● ● ●
CardStock ● ● ●
Labels ● ● ●
Transparency ● ●
Envelope
●
● (only for
optional tray 2)
●
Preprinted ● ● ●
Cotton ● ● ●
Recycled ● ● ●
Archive ● ● ●
Hole Punched ● ● ●
(●: Supported, Blank: Not supported)
When you use recycled paper as a used paper, printouts might be
wrinkled and/or jamming may occur due to excessive curl.
Envelope
Successful printing on envelopes depends upon the quality of the enve-
lopes.
To print an envelope, place it flap side up with the stamp area bottom the
top right side.
• When selecting envelopes, consider the following factors:
- Weight: The weight of the envelope paper should not exceed
90 g/m
2 otherwise, jam may occur.
- Construction: Prior to printing, envelopes should lie flat with less
than a 7 mm curl and should not contain air.
- Condition: Envelopes should not be wrinkled, nicked, either dam-
aged.
- Temperature: Use envelopes that are compatible with the heat and
pressure of the machine during operation.
• Use only well-constructed envelopes with sharp-and well-creased folds.
• Do not use stamped envelopes.
• Do not use envelopes with clasps, snaps, windows, coated lining,
self-adhesive seals, or other synthetic materials.
• Do not use damaged or poorly made envelopes.
• Be sure the seam at both ends of the envelope extends all the way to
the corner of the envelope.
2 1
1 Acceptable
2 Unacceptable
• Envelopes with a peel-off adhesive strip or with more than one flap that
folds over to seal must use adhesives compatible with the machine’s
Types Tray 1 Optional tray
Multi-purpose
tray
