PS200/CH200 12 V Charging Regulators

TABLE 6-1. PS200/CH200 Settings

Continuous
Charge Source
Current Limit
(A)

The maximum amount of current applied to the battery while being float charged. User
adjustable for any battery family. Default value is 1.1 Amps.

SDI-12
Address

Allows the user to set the SDI-12 address of the PS200/CH200. Factory default for this address
is 0. Each SDI-12 sensor connected to a port of an SDI-12 recorder (datalogger) should have a
unique SDI-12 address. See Section 6.2, SDI-12.

Battery
Voltage
Multiplier.
Not user
adjustable.

Calibration multiplier for battery voltage measurement. “Factory Defaults” button does not affect
calibration values.

Continuous
Charge Source
Voltage
Multiplier.
Not user
adjustable.

Calibration multiplier for continuous source voltage measurement. “Factory Defaults” button
does not affect calibration values.

Regulator
Input Voltage
Multiplier.
Not user
adjustable.

Calibration multiplier for regulator input voltage measurement. “Factory Defaults” button does
not affect calibration values.
