4.3 Charging Sources
Campbell Scientific Solar Panels
SP10 SP20 SP50 SP90
Peak Power 10 W 20 W 50 W 90 W
Voltage @ Peak Power 16.8 V 16.8 V 17.5 V 17.8 V
Current @ Peak Power 0.59 A 1.19 A 3.9 A 4.8 A
Notes:
1. Specifications assume a 1 kilowatt per square meter illumination and a
solar panel temperature of 25 °C (77°F).
2. Individual panels may vary up to 10%.
3. The output panel voltage increases as the panel temperature decreases,
which is in the same direction as the recommended VRLA battery
charging voltage change with temperature.
4. Higher latitudes and less sun hours during winter months might require a
larger panel than what is required to keep the battery charged during the
summer.
AC/DC Transformer with Interchangeable Blades: Campbell Scientific
Model No. 29796-US
Input Voltage: 100 – 240 VAC
Input Frequency: 47 – 63 Hz
Output Voltage: 24 Vdc
Output Current (max): 1.67 A
Protection: Unit will auto-recover upon removal of fault.
UL Approval: UL60950-1 2 nd Edition
Unit has interchangeable blades. Unit ships with US/Canada plug installed.
For international orders select option 29798 –IP for international blades.
International blade selection contains blades for Australia/New Zealand, UK,
Europe/South America, Korea, Argentina, China, & India/South Africa.
AC/DC DIN Rail Mount Power Adapter: Campbell Scientific Model No.
28370
Input Voltage: 85 – 240 VAC or 90 – 350 VDC
Input Frequency: 45 – 65 Hz
Output Voltage: 24 Vdc
