PS200/CH200 12 V Charging Regulators
TABLE 6-1. PS200/CH200 Settings
Battery
Family This field displays which battery family type the PS200/CH200 is configured to use. Available
battery types are selected using a drop-down menu. See Section 6.1.2.1, Battery Families, for
more information.
Custom
Battery Cycle
C
0
25ºC Cycle
Charge
Voltage (V)
This field will allow changes made to it when “Custom Battery” is selected for the battery
family. This field will be grayed out for any other battery family types and not allow changes
made to it. See battery manufacturer information for correct values. See FIGURE 6-3.
Custom
Battery Cycle
C
2
First Order
Coefficient
(mV/ºC)
This field will allow changes made to it when “Custom Battery” is selected for the battery
family. This field will be grayed out for any other battery family types and not allow changes
made to it. See battery manufacturer information for correct values. See FIGURE 6-3.
Custom
Battery Cycle
C
2
Second
Order
Coefficient
(mV/ºC)
2
This field will allow changes made to it when “Custom Battery” is selected for the battery
family. This field will be grayed out for any other battery family types and not allow changes
made to it. See battery manufacturer information for correct values. See FIGURE 6-3.
Custom
Battery Float
C
0
25º Cycle
Charge
Voltage (V)
This field will allow changes made to it when “Custom Battery” is selected for the battery
family. This field will be grayed out for any other battery family types and not allow changes
made to it. See battery manufacturer information for correct values. See FIGURE 6-3.
Custom
Battery Float
C
2
First Order
Coefficient
(mV/ºC)
This field will allow changes made to it when “Custom Battery” is selected for the battery
family. This field will be grayed out for any other battery family types and not allow changes
made to it. See battery manufacturer information for correct values. See FIGURE 6-3.
Custom
Battery Float
C
2
Second
Order
Coefficient
(mV/ºC)
2
This field will allow changes made to it when “Custom Battery” is selected for the battery
family. This field will be grayed out for any other battery family types and not allow changes
made to it. See battery manufacturer information for correct values. See FIGURE 6-3.
Custom
Battery
Minimum
Charge
Voltage (V) Minimum voltage that the PS200/CH200 will put across a battery configured as “Custom
Battery” in the Battery Family field. Voltage applied across a battery is dependent on
temperature. The higher the battery temperature the lower the voltage applied across the battery.
