PS200/CH200 12 V Charging Regulators
3.5 Turn On the Charging Source
Turn on the power going to the charging source or uncover the solar panel.
The “CHG” LED should flash green approximately every 4 to 5 seconds if all
incoming connections are correct and there is an adequate charging voltage
present.
3.6 Turn On Power to the Datalogger
Flip the switch on the PS200/CH200 supply to “On”. Verify voltage to the
datalogger with a volt meter, or use a key pad display, or connect to the
datalogger with a laptop or PDA to make sure the datalogger is running
correctly.
3.7 LED Indicators
As previously mentioned, the PS200/CH200 has two LED indicators, the
CHARGE LED and the CHECK BATTERY LED. The following tables
illustrate the various conditions and associated colors for the CHARGE and
CHECK BATTERY LEDs.
TABLE 3-1. CHARGE LED
Condition Color
No Valid Charge Source Off
Valid Charge Source & Charging Battery Flashing Green
Valid Charge Source but Battery being Discharged Flashing Orange
Regulator Fault Detected Flashing Red
Waiting for New Operating System (Section 6.2.2, SDI-12
Measurements) Solid Red
Transferring Operating System Solid Green
TABLE 3-2. CHECK BATTERY LED
Condition Color
Battery Voltage > 11.5 V Off
10.5 V ≤ Battery Voltage ≤ 11.5 V Flashing Orange
Battery Fault Detected OR Battery Voltage < 10.5 V Flashing Red
