Chatsworth Products CPI Power Management Tool - Manual (Page 15)

Power Management Tool Manual March 2014
Chatsworth Products, Inc. (CPI) 15
2. By typing the URL directly in the address bar of a browser
From a computer on the same network as the server, enter the following default
URL in your web browser to launch the DCM Console:
http://localhost:8688/DcmConsole/ (Note: DcmConsole is case sensitive)
For example, from the factory set IP, the address would be:
http://192.168.123.122:8688/DcmConsole
NOTE
The letters of 'D' and 'C' in DcmConsole are capitalized.
Be sure to use the latest version of your browser.
The login screen will appear. Enter the User Name and Password that you were
issued after product registration. Leave Domain blank. Click the Log In button.
The main screen (dashboard) will appear.
See the next section.
