Flytec 6030-GPS
30 / 62
Example:
counterclockwise
To enter arc segments, then the following sequence must
be observed:
Long, Lat centre;
Long, Lat start point of arc segment;
Long, Lat end point of arc segment;
Rotational direction (+clockwise, - counterclockwise)
For circles the centre and the Radius are sufficient
Long, Lat of centre;
Radius in km
CTR1 Alpnach
=================
Point 1/7
Point 2/7
Center 3/7
Startb. 4/7
Stopb. 5/7
Point 6/7
================⇓
Point
Lat N 47’00.783
Lon E008’17.917
Ins Del
Ele Ele
7. Point
6. Point
5 Stopboarder
Dir -
4 Startboarder
Dir -
3 Center
2. Point
1. Point
6. Point
1. Point
2. Point
