Flytec 6030-GPS
12 / 62
AscentF
Basic Tone pitch
Is the frequency audible at starting climb tone.
Factory setting 1200 Hz
Modul.
Increase Tone pitch
The interrelation may be seen on graphic below.
Factory setting = 4
0 2 4 6 8 10 12 14
500
100
15 00
2 00 0
25 00
30 00
Ton
Frequen
Hz
Vario
Increasing tone -slow
Increasing tone -fast
Basi – 1000 z
Basi – 500 H z
SinktoneF
Basic Tone pitch
Tone Pitch at starting Sink tone. The Sink tone is continuous
and is heard with deeper sound Pitch at increasing sink speed,
and is slowly increasing in frequency when approaching rising
air. The basic tone Pitch of sink acoustics may only be set
equally to the basic tone Pitch for climb acoustics.
The descent tone may be switched-off by briefly pressing
the key ; /Route and also be switched-on again; then one
would hear the dedicated tone and the analogue Vario display
would show the relevant starting point. The starting point of
sink tone is set in Set-Mode under "Basic Settings / Sink Tone
threshold".
damp
Dampening
The Variometer value is recalculated every 0.2s. In case of
rapid Vario changes between two calculation phases,
it may result in a quite intense variation of frequency. The ear
perceives this incidence as a kind of fast „piano effect“.
In order to diminish this effect, a damping feature is fitted.
The relevant factory setting is 8. Rapid tone pitches are honed
in the frequency. As a result, the Vario sound is then smoother.
Beepch
Beepchoose
At setting of „0“ the single beep of climb acoustic has a fixed
frequency; at setting “1” the climb acoustic also changes during
the beep.
