5. Replace the five securing screws on the top panel.
Insert the FFC flush with the connector and secure
the latch as shown.
Insert the FFC flush with the connector and secure the
latch as shown.
Insert the FFC flush with the connector and secure
the latch as shown.
Insert the FFC flush with the connector and secure the
latch as shown.
