-36-
APPENDIX “E” - ORDERING INFORMATION
MODEL NO. DESCRIPTION
NPN O.C. *
OUTPUT(S)
RELAY
OUTPUT(S)
RS485
REPLACEMENT
RELAY OUTPUT
BOARDS 85 TO 250 VAC 18-36 VDC/24VAC
C48TS
1 Preset Timer, Reflective LCD Yes Yes No RBC48001 C48TS003 C48TS013
C48TD
1 Preset Timer, Backlit LCD Yes Yes No RBC48001 C48TS103 C48TS113
2 Preset Timer, Reflective LCD No Yes No RBC48003 C48TD002 C48TD012
2 Preset Timer, Reflective LCD No Yes Yes RBC48003 C48TD007 C48TD017
2 Preset Timer, Reflective LCD Yes No Yes N/A C48TD005 N/A
2 Preset Timer, Backlit LCD No Yes No RBC48003 C48TD102 C48TD112
2 Preset Timer, Backlit LCD No Yes Yes RBC48003 C48TD107 C48TD117
2 Preset Timer, Backlit LCD Yes No Yes N/A C48TD105 N/A
MODEL DESCRIPTION PART NUMBER
SFC48 PC Configuration Software For Windows 3.x and 95 (3.5" disk) (for RS-485 Models) SFC48
ACCESSORIES
PART NUMBER FOR AVAILABLE
SUPPLY VOLTAGES
* PNP O.C. Output(s) versions available. Contact the Factory.
