The operating modes of the C48T are programmed using the front panel
keypad. (See page 12, for details on using the keypad to program the unit)
Accessibility to the Programming Menu depends on the Program Disable
Function setting (See page 11, for available program disable settings).
PROGRAMMING MENU
Numeric Value Entry Method
Configures push button response for entering numeric
data values such as Presets and Output Times
Timer Range
The timer range determines the time units to be used.
trAnGE
SEC.0
-13-
Timer Operating Mode
The charts on the following pages, show operating
modes for the Single Preset and Dual Preset Timer Models.
In the descriptions below, the “Main Preset” or “Output”
refers to “Preset 1” or “Output 1” on the Single Preset
Model. On the Dual Preset Model it refers to “Preset 2” or
“Output 2”.
Reset Type:
Auto - Unit automatically resets as programmed, when timer triggers main
preset’s output or at it’s timed output end.
Manual - Unit does not reset when timer triggers main preset’s output or at
it’s timed output end. The timer value can be manually reset by a User
Input or by Serial Communications command.
Reset to:
Zero - When reset (manually or automatically) timer value goes to zero. The
Main Preset Output is triggered when timer value reaches main Preset
Value.
Preset - When reset (manually or automatically), the main Preset value is
loaded into the timer value. The main Preset Output is triggered when
timer value reaches zero.
At Timed Output End:
When this mode is selected, Auto Reset occurs when the main preset’s
Output time elapses and the main output deactivates. If not selected, Auto
reset occurs when the main output is triggered.
Continue Timing at Main Output:
The timer continues timing when main output is triggered. To stop timing,
the “Run/Stop” terminal is put into the “Stop” state. This mode is useful for
repetitive, auto-cycling applications.
Stop Timing at Main Output:
The timer will stop when the main preset’s output is triggered. To resume
timing, a manual reset (User Input -
rSt-E ) is performed, which resets the
output and the stop condition. The Run/Stop input can also be used to restart
the timer by putting it in the “Stop” state and then back to the “Run” state.
Cycling the Run/Stop however, will not reset or affect any outputs. This
mode is used to provide “one-shot” capability.
OPEr
11
USER INTERFACE/PROGRAMMING MODES
MODE DESCRIPTION
diGit The digit entry method allows the selecting and
incrementing of each numeric digit on an
individual digit-by-digit basis.
AutoSc
EntrY
AutoSc
1 hour
0.01 hr
0.1 hr
1 min
0.1 min
999999 Hours
9999.99 Hours
99999.9 Hours
9999.59 Hours.Minutes
999.59.9 Hours.Minutes.0
h
h.00
h..0
h.n
h.n.0
0.01 min 99.59.99 Hours.Minutes.00 h.n.00
1 sec 99.59.59 Hours.Minutes.Seconds h.n.SEC
0.1 sec 999.59.9 Minutes.Seconds.0 n.SEC.0
1 sec 9999.59 Minutes.Seconds n.SEC
0.1 min 99999.9 Minutes n.0
0.01 min 9999.99 Minutes n.00
0.001 min 999.999 Minutes n.000
1 sec 999999 Seconds SEC
0.1 sec 99999.9 Seconds SEC.0
0.01 sec 9999.99 Seconds SEC.00
0.001 sec 999.999 Seconds SEC.000
RESOLUTION RANGE MODE
The auto scrolling method allows pressing and
holding the “up” or “down” keys to progressively
change all digits of the data value, similar to
incrementing or decrementing a counter.
