SINGLE PRESET OPERATING MODES
Use either of the two charts on this page for more information on specific
operating modes.
-14-
Stop Timing at 01, Auto Reset to Preset 1 at 01 End, Timed Output
Stop Timing at 01, Manual Reset to Zero, Latched Output
Stop Timing at 01, Auto Reset to Zero at 01 End, Timed Output
Stop Timing at 01, Auto Reset to Preset 1, Timed Output
Continue Timing at 01, Auto Reset to Zero at 01 End, Timed Output
Stop Timing at 01, Auto Reset to Preset 1, Latched Output
Continue Timing at 01, Auto Reset to Preset 1, Timed Output
Stop Timing at 01, Auto Reset to Zero, Timed Output
Continue Timing at 01, Auto Reset to Zero, Timed Output
Stop Timing at 01, Auto Reset to Zero, Latched Output
Continue Timing at 01, Manual Reset to Preset 1, Timed Output
Stop Timing at 01, Manual Reset to Preset 1, Timed Output
Continue Timing at 01, Manual Reset to Preset 1, Latched Output
Stop Timing at 01, Manual Reset to Preset 1, Latched Output
Continue Timing at 01, Manual Reset to Zero, Timed Output
Stop Timing at 01, Manual Reset to Zero, Timed Output
Continue Timing at 01, Manual Reset to Zero, Latched Output
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
18
9
17
8
16
7
15
6
14
5
13
4
12
3
11
2
10
1
SINGLE PRESET OPERATING MODES
RESET TYPE RESET OUTPUT 1
Single
Preset
Modes Manual
Auto
T
o
Zero
T
o
Preset
1
at
T
imed
Output
End
Latched
T
imed
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
MODE#
Output 1: (Main Output for Single Preset Model)
Latched - When Output 1 activates it stays activated or latched until it is
manually reset.
Timed - When Output 1 is activated it stays activated for the time specified
by the Output 1 Time Value. Output 1 deactivates after the Output 1 time
elapses.
O1 Off at O2: (Dual Preset only)
Output 1 activates at Preset 1. It deactivates when Output 2 is activated.
(Does not apply to activation from Serial command.)
Output 2: (Dual Preset Model only; Main Output)
Operates similarly to Output 1 Latched and Timed modes.
Continue Timing at 01, Auto Reset to Preset 1 at 01 End, Timed Output
CONTINUE
T
iming
at
01
ST
OP
T
iming
at
01
