Print and Reset Timer Value
This parameter is used in conjunction with a Print
Request (User Input or Serial Command) and the Print
Options to determine whether or not the timer value is reset
after the value is acquired for serial transmission.
Factory Settings
This parameter is used to reset all parameters to their
factory defaults. The Factory Settings chart below shows
settings for each programming parameter.
-22-
PrnrSt
no
MODE DESCRIPTION
no Do not reset timer value after Print.
YES The Timer Value, when specified in Print Options
will reset after being printed (transmitted on
Serial) when a Serial or User Input Print Request
is issued.
FAcSEt
no
MODE DESCRIPTION
no Do not reset parameters to Factory Settings.
YES Reset all programming parameters to their
Factory Settings.
EntrY NUMERIC VALUE ENTRY METHOD AutoSc
trAnGE TIMER RANGE SEC.0
rSt.P.uP
OPEr
TIMER RESET AT POWER-UP
TIMER OPERATING MODE
no
11
PRESETS 2 1
Ac PrS ACCESS PRESET VALUE -y-y
PrESEt PRESET 1 VALUE 1.0
PrESEt PRESET 2 VALUE (Dual Preset only) 2.0
P1trAc P1 TRACK P2 (Dual Preset only) no
FACTORY SETTINGS CHART *
OUTPUTS
USER INPUTS
2 1
Ac Out ACCESS OUTPUT TIME VALUES -L-L
OutrES OUTPUT RESOLUTION 0.01SEC
OutPut OUTPUT 1 TIME 0.10
OutPut OUTPUT 2 TIME (Dual Preset only) 0.10
rEVOut REVERSE RELAY/OUTPUT LOGIC -n-n
rEVAnu REVERSE ANNUNCIATOR LOGIC -n-n
OutP.uP OUTPUT POWER-UP STATE -f-f
USrIn1 USER INPUT 1 rSt. -L
USrIn2 USER INPUT 2 rSt. -L
USrIn3 USER INPUT 3 rSt. -L
USr F1 USER F1 KEY rSt. -L
CodE PROGRAMMING CODE VALUE 0
ScroLL SCROLL DISPLAY no
RS-485 SERIAL OPTION (Dual Preset only)
SErSEt SERIAL BAUD RATE & PARITY 96n
SErAdr SERIAL UNIT ADDRESS 0
SErAbr ABBREVIATE SERIAL MNEMONICS no
PrnrSt
PrnOPt
PRINT & RESET TIMER VALUE
PRINT OPTIONS
no
3
* Settings shown for Dual Preset model. For Single Preset model, changes to
Factory Settings are as follows:
2.0 PRESET 1 VALUE PrESEt
5 TIMER OPERATING MODE OPEr
