PrnOPt
3
Timer
Value
Preset
Values
PRINT
01 √
02 √
03 √ √
Serial Abbreviate Mnemonics
When transmitting data, the unit can be programmed to
suppress the address number, mnemonics, and some spaces
by selecting
YES for this parameter. A selection of YES
results in a faster transmission and may be useful when
interfacing with a computer. However, when interfacing
with a printer, sending mnemonics is usually desirable.
Print Options
The Print Options parameter determines which values
are printed in response to a Print Request command or user
input print request.
Serial Baud Rate and Parity Settings
This parameter configures the Baud Rate and Parity
Settings for RS485 Serial Communications.
Serial Unit Address (00-99)
This parameter configures the Serial Unit Address. This
address is used to uniquely identify each unit when multiple
units are connected on an RS485 bus.
-21-
SErSEt
96n
SErAdr
0
SErAbr
no
DESCRIPTION
12n 1200 Baud; No Parity (8 data bits)
12o 1200 Baud; Odd Parity (7 data bits)
12E 1200 Baud; Even Parity (7 data bits)
24n 2400 Baud; No Parity (8 data bits)
24o 2400 Baud; Odd Parity (7 data bits)
24E 2400 Baud; Even Parity (7 data bits)
48n 4800 Baud; No Parity (8 data bits)
48o 4800 Baud; Odd Parity (7 data bits)
48E 4800 Baud; Even Parity (7 data bits)
96n 9600 Baud; No Parity (8 data bits)
96o 9600 Baud; Odd Parity (7 data bits)
96E 9600 Baud; Even Parity (7 data bits)
MODE
MODE DESCRIPTION
no
YES
Unit sends Serial Address, Value Mnemonic, and
right justified numeric value when a serial
Transmit Value command, a Print Request
command, or User Input Print Request is issued.
A 400 msec “printer delay” is inserted between
each value when a Serial Print Request command
or User Input Print Request is performed.
Only the numeric data value is transmitted when a
serial Transmit Value command, Print Request
command or User Input Print Request is issued.
No unit address, mnemonics, or 400 msec printer
delay are transmitted. This option is beneficial
when communicating with a computer and faster
data throughput is desired.
MODE
NUMBER
The next five parameters pertain to serial communications and are only
found on Dual Preset units with the RS-485 serial option installed.
