ENG

Grease the internal drive tube and reassemble the shielding on the

driveshaft.

Check the length of the driveshaft at its the minimum and maximum

extensions on the implement.

TROUBLESHOOTING

WEAR OF YOKE EARS

EXCESSIVE WORKING ANGLE

• Reduce the working angle.

• Disengage PTO when joint angle exceeds 45°.

DEFORMATION OF YOKES

EXCESSIVE TORQUE PEAK OR SHOCK LOAD

• Avoid overloading or engaging PTO when under load.

• Check the efficiency of the torque limiter.

BROKEN CROSS ARMS

EXCESSIVE TORQUE PEAKS OR SHOCK LOAD

• Avoid overloading or engaging PTO when under load.

• Check the efficiency of the torque limiter.

ACCELLERATED WEAR OF CROSS ARMS

EXCESSIVE LOAD

• Do not exceed the speed or power limits indicated in the instruction manual.

INSUFFICIENT LUBRICATION

• Follow instructions at point 33.

SEPARATION OF TELESCOPING TUBES

EXCESSIVE EXTENSION OF DRIVELINE

• Do not extend driveline to the point that the tubes separate.

• For stationary machinery, position the tractor so the telescoping tubes overlap

as illustrated in point 10.

TWISTING OR BENDING OF TELESCOPING TUBES

EXCESSIVE TORQUE PEAK OR SHOCK LOAD

• Avoid overloading or engaging PTO when under load

• Check the efficiency of the torque limiter.

• Check that driveline does not come into contact with tractor or implement

components during manoeuvres.

ACCELERATED WEAR OF TELESCOPING TUBES

INSUFFICIENT LUBRICATION

• Follow instructions from point 29 to point 33.

INSUFFICIENT TUBE OVERLAP

• Follow instructions at point 10.

ACCELERATED WEAR OF SHIELD BEARINGS

INSUFFICIENT LUBRICATION

• Follow instructions at point 33.

All the plastic parts of BP C.H.M. drivelines are totally recyclable. Protect

the environment by disposing of used plastic parts properly at the time of

replacement.
