Vaisala HMT330 - Manual (Page 80)

User's Guide _______________________________________________________________________
78 ___________________________________________________________________ M210566EN-K
Example (set Tdf and T as display alarm quantities and configure the
alarms as prompted):
>alsel tdf t
Al1 Tdf above: 80.00 'C ? 0
Al1 Tdf below: - ?
Al1 Tdf hyst : 1.00 'C ?
Al1 Tdf enabl: ON ?
Al2 T above: 40.00 'C ? 30
Al2 T below: - ?
Al2 T hyst : 1.00 'C ?
Al2 T enabl: ON ?
>
MI70 Link Program for Data Handling
MI70 Link is a support program that enables you to handle the
measurement data of your Vaisala transmitter using a Windows PC.
Using the MI70 Link you can, for example:
- Monitor the transmitter’s measurement readings directly using the
real-time window function.
- Transfer recorded data from the main transmitter memory in numeric
or graphical format, for further use in a spreadsheet program (such as
Microsoft
Excel) or virtually any other application. Note that the
maximum amount of data points that can be downloaded in one
transfer is 65000.
To use the MI70 Link program, you must connect your Windows PC to
the service port of the transmitter with a serial or USB cable. The MI70
Link program, and the optional connection cables, are available from
Vaisala. See section Spare Parts and Accessories on page 178.
Follow the steps below to connect your transmitter and start using the
MI70 Link:
1. Connect your PC to the service port of the transmitter. Refer to
section Service Port Connection on page 81.
2. Check that the HMT330 is powered.
3. Start the MI70 Link program.
4. Start using the program. There is usually no need to select a COM
port manually, the MI70 Link software can detect it automatically.
NOTE For instructions on using the MI70 Link, see the program’s online help.
