PFadvantage Cotton Yield Monitor
Ag Leader Technology General
September 2005 1-5
Display and
Display Selection
Keys The PFadvantage Cotton Yield Monitor has four display lines for viewing
items on the main operating screen. You can choose which items you see
on the display and the position that the items appear on the display.
To change a display item on a display line you must select the line. The four
display selection keys to the right of the display each select a display line.
A rectangular box surrounds the display line to show that it is selected.
When the display line is selected the four menu items on the bottom change
and show items you can select for display. Press a key below one of the
four display items to put a different display item in place of the selected
display item. There are more than four display items to choose for viewing.
Press the bottom LEFT or RIGHT ARROW keys to scroll to the right or left
and view other display items on the bottom.
Figure 2: Main operating screen
Up and
Down
Arrow
Symbol
Selection
Box
Card
Symbol
When arrows present,
press bottom arrow keys
to display additional
menu or display items
