PFadvantage Cotton Yield Monitor
Boundary Ag Leader Technology
September 2005 4-50
1 Position the vehicle at a starting point on the outside of the
field.
2 Press START BOUNDARY key and drive the outside edge of
the field.
3 Use the PAUSE/CONTINUE feature to drive around an
obstacle (wet spot) without including the path around the
obstacle in the boundary map. When you reach the obstacle,
press the PAUSE key. Drive around the obstacle and press
CONTINUE key. The PF will draw in a straight line across
the void area in the boundary map.
4 When you have completed driving the boundary of the field,
press the STOP BOUNDARY key. Then press the SAVE
BOUNDARY key.
NOTE: You should drive back to the starting point before
pressing STOP BOUNDARY key. If you do not, the area
calculated for the field may be inaccurate.
5 Press EXIT key and repeat above steps for other fields. Refer
to the gridding instructions to grid the field.
BOUNDARY SETUP DG
FIELD NAME
SMITH
042.0186450 N
093.6337050 W
GROUND SPEED
21.3 mph
AREA
N 19.737 acres
SAVE
BOUNDARY
CANCEL
IMPORTANT: The Boundary and Grid screens are the only
location where you can view the FIELD AREA information. If you
come back to review information, DO NOT SAVE GRID OR
BOUNDARY AGAIN. If you do this you will lose the boundary
for this field. After reviewing the information, press EXIT key.
***
