PFadvantage Cotton Yield Monitor
Ag Leader Technology
General
September 2005
1-9
Header Height
Sensor
Below is an example of a header height sensor installed underneath a
machine cab. The header height sensor tells the monitor the position of the
drums so that when the head is raised on the end rows, the monitor stops
counting area.
Figure 5: Header Height Sensor
Header Sensor
