PFadvantage Cotton Yield Monitor
General
Ag Leader Technology
September 2005
1-8
Emitter
Detector
Flow Sensor
Below is an example of a flow sensor. On all cotton machines, the flow
sensor installs on the basket duct. The flow sensor measures the cotton
weight in pounds as you harvest. The flow sensor measures the cotton
weight when the cotton passes between the emitter and detector.
Figure 4: Flow Sensor
