6.3 Overview of the Recovery Manager GUI
3PAR Recovery Manager 4.1.0 For Microsoft Exchange 2010 User’s Guide
Figure 6-1. Recovery Manager GUI Overview
6.1.1 Menu Bar
The menu bar consists of the following menu items:
■ Console menu - allows you to exit the GUI and register the server.
■ Actions menu - allows you to access virtual copy functionality.
■ Help menu - provides an About 3PAR Recovery Manager screen and access to other
helpful links such as descriptions for event messages may be generated during operation.
6.1.2 Node Tree Pane
The node tree presents the system’s servers. When the Recovery Manager GUI starts, it analyzes
the servers’ Mailbox Databases, mailbox information, and virtual copies, then displays them
graphically as a nested tree in the left pane.
NOTE: The GUI is not available for the Recovery Manager Agent for Exchange
Server installations.
