Basic Installation 2-5

Installing the

Tower Module in a

CD-ROM Tower

If you are installing a CD-ROM Stand-Alone Module, or if your
Tower Module has already been installed in a tower, you can skip
this section.

The HP CD-ROM Server Tower Module is intended to be
installed in standard CD-ROM towers. The dimensions of the
CD-ROM server are the same as for standard CD-ROM drives,
which is 5.25 inch half-height.

To install the CD-ROM server, follow the steps below:

WARNING

❏ To avoid the risk of electrical shock or other injury,

disconnect power from the tower before removing the
cover, chassis, or enclosure.

Prepare the CD-ROM tower for the installation, for example,
remove the chassis cover.

Record the LAN hardware (MAC) address of the CD-ROM
server. You will need this number during the network
configuration described in chapter 3. The address is found on
the label on the bottom of the server.

Note

❏ An additional label that identifies the same LAN hardware

address is included with the CD-ROM server tower module.
This label is intended to be attached to the outside of the tower
chassis (the CD-ROM server may not be accessible after it is
installed).

Refer to the tower installation instructions for additional
hardware to be assembled onto the CD-ROM server prior to
installation.

Slide the CD-ROM server into the tower.
